FRAME: Choose from folding crossbrace or rigid strut tube type aluminium frame. Both the crossbrace and strut tubes can grow in width up to 75mm.

SEAT: A growing seat pan is optional.

BACKREST: Standard: Supplied without backrest or upholstery but with stroller handle back posts for attachment of upholstery or solid backs. Back posts are available in low, medium and tall heights.
Options: Back posts with growing adjustable upholstery, swing away adjustable stroller handles, removable stroller extension handle.

ARMRESTS: Standard: Lift up or T-arms.
Options: Adjustable locking lift up, locking length adjustable lift up. Desk length or full length armrests.

LEGRESTS: Choose from swingaway legrests where the footplates are mounted onto the tube of the legrest, or swinagway where footplates mount onto extension tubes coming out of the base of the legrests, or heavy duty lift off legrests. When footplates mount to an extension tube type legrest, then the angle of the legrest can be 60 or 70 degree. When mounted to the legrest itself the legrest angle can be 70 or 80 or 90 degrees.
A 90 degree elevating legrest is optional.

FOOTPLATES: With swing legrests where the footplates are mounted to entension tubes, footplate choices include: composite, aluminium, kids angle adjustable. Options at extra cost: Adult angle adjustable footplates or lift up platform footrest.
Where the footplates mount directly to the legrest, or the heavy duty legrest option, standard footplate options are: kids angle adjustable with leg strap, or, 90 degree footboard with leg strap. Option to upgrade to adult angle adjustable footplates.

WHEELS: 500mm, 550mm, 600mm diameter wheels are standard choices. 300, 400 and 450mm diameter options at extra cost. Standard push rims are anodised aluminium. Plastic coated push rims and push rims with vertical or oblique projections are optional.
A one arm drive kit can also be fitted to chair with a seat width of 325mm or greater.
Pneumatic or low polyurethane tyres are standard. Options: airless inserts, full polyurethane, high pressure clincher or kevlar tyres.

CASTORS: Standard: 125mm low profile polyurethane.
Options: 75 or 100mm light up, 125x40mm or 150mm narrow or 150x40mm polyurethane, 200mm pneumatic, 200x40mm polyurethane, 200x50mm pnuematic, airless inserts.

TRANSPORTATION: Can be ordered with front and rear tie down anchor points fitted to the frame.

Options

Positioning belt
Tray
Spoke guards
Crutch holder
Backpack
Seat pouch

Crash Test Information for Wheeled mobility devices

This wheeled mobility device meets the design requirements and has been successfully crash tested in accordance with ANZS/ISO 7176-19:2008 MOD. This standard relates to the design requirements specified for a wheeled mobility device to be used to transport an individual in a motor vehicle.

Manufacturer/Country

Sunrise Medical / United States of America

Maintenance

Refer to the supplier and manufacturer manual for maintenance instructions and safety warnings.
