General Details

Crash Test Information for Wheeled mobility devices

This wheeled mobility device meets the design requirements and has been successfully crash tested in accordance with ANZS/ISO 7176-19:2008 MOD. This standard relates to the design requirements specified for a wheeled mobility device to be used to transport an individual in a motor vehicle.

Manufacturer/Country

Sunrise Medical / United States of America

Warranty

Limited lifetime warranty on frame and cross-brace; limited 1-year warranty for all Sunrise-made parts and components

Websites

• Sunrise Medical - http://www.sunrisemedical.com.au/products/zippie/childrens-wheelchairs/iris.aspx

Maintenance

Refer to the supplier and manufacturer manual for maintenance instructions and safety warnings.

Models / Specifications

Features

Contact listed suppliers to confirm features, options and models available.

Accessories

• Wheelchair accessories:
  • anti-tips
  • back pack
  • positioning belts
  • spoke guards
  • sun canopy
  • tray table
  • under seat bag

Transport and Dismantling

• Wheelchair transport:
  • backrest can be folded down for transport
  • folds for transport
  • seat can be removed for transport
  • secure by transport approved tie down points for user sitting in the wheelchair

Brakes

• Manual Wheelchair brake options:
  • foot operated brakes
  • lever type
• Manual Wheelchair brakes:
  • push to lock

Wheels

• Wheelchair tyre options:
  • foam filled
  • solid
• Wheelchair castor options:
  • light-up microcellular
  • pneumatic
  • semi-pneumatic
• Wheelchair tyres:
  • pneumatic
  • quick release axles
• Wheelchair castors:
  • solid

Footplates

• Wheelchair footplate options:
  • angle adjustable
  • extension
  • heel loops
  • lift up platform
  • one piece
  • toe loops
• Wheelchair footplates:
  • height adjustable
  • lift up
  • swing away
  • two piece

Legrests

• Wheelchair legrest options:
  • angle adjustable
  • articulating
  • elevating (manual)
  • heavy duty
  • impact guards
  • removable
  • stump supports
• Wheelchair legrests:
  • leg strap
  • length adjustable
  • removable
  • swing away

Armrests

• Wheelchair armrest options:
  • contoured
  • depth adjustable
  • fixed height
  • full length
  • gutter arm supports/troughs
  • height adjustable
  • lift up
  • padded
  • sideguards
• Wheelchair armrests:
  • desk length
  • height adjustable

Headrest

• Wheelchair headrest options:
  • depth adjustable
  • fully customisable (the wheelchair is compatible with a large range of headrests)
  • height adjustable
  • removable

Backrest

• Wheelchair backrest:
  • aluminium
  • folds down onto the seat for transport
  • no backrest (a large range of backrests can be fitted)
• Wheelchair backrest options:
  • angle adjustable (manually)
  • a range of off-the-shelf backrest options available
  • contoured
  • fixed lateral supports
  • height adjustable
  • padded
  • shock absorber
  • stabiliser bar
  • swing away lateral supports

Seat

• Wheelchair seat options:
  • depth adjustable
  • height adjustable
  • no seat (a large range of seating systems can be fitted)
  • width adjustable
• Wheelchair seat:
  • flat seat pan (for use with a large range of cushions)

Frame

• Manual Wheelchair frame:
  • aluminium
  • rigid
  • tilt in space
• Manual Wheelchair frame options:
  • approved tie down points
  • folding
  • one arm drive
  • self propelling
  • transit
