General Details

Extra product information

Features
• Electronic High / Low / Tilt (Optional)
• Electronic anti-jam Backrest & knee bend
• Epoxy coated & anti-rust treated steel frame
• Custom Jomor "Steri Hinge" deck hinges for greater strength & precision
• Teflon coated pivot bushes for smooth & quiet operation
• Removable Head and Foot panels
• Removable Hygienic ABS deck panels
• 2 x overhead pole sockets
• Safe working load: 250 kg
• Mattress size: 900 x 1900 mm
• Min / max height: 180 mm - 770 mm
• Castor sizes - 75mm, 100mm, 125mm (Long Double only available with 100mm diameter castors)
• Hoist clearance: infinite

Meets DHHS (Victoria) requirements with addition of full width head and foot boards.

Available Sizes
• Single
• Long Single
• Wide Single
• King Single
• Long Double

Caution: Bed Rails / Bed Sticks

Careful consideration needs to be taken when choosing a bed rail or stick. Incorrect positioning of the bedrail can lead to injury or death. They may increase the risk of injury to the occupant in several ways. Entrapment of limbs or body parts may occur within the rails, or between the rails and the bed. This may occur to those having a seizure, or rolling over in bed, or if unstable while transferring out of bed.
Bed rails can cause some occupants to become anxious while in bed. They may try to climb over the rails, particularly if the occupant has a condition such as dementia.
May not be suitable for a person who has ; a cognitive impairment with or without reduced mobility; reduced alertness and/or disorientation; a history of falls from bed.
It is recommended to check regularly that the bed stick is always positioned as close to the mattress edge as possible.
It should not be used in circumstances where there is a gap between the bed stick and the mattress, or potential gap if the device or mattress moves due to possible risk of entrapment.
A risk assessment is recommended prior to provision
For further information:
http://www.otaus.com.au/sitebuilder/advocacy/knowledge/asset/files/21/otapositionpaper-bedstickuse(march2015-final).pdf

Manufacturer/Country

Contact supplier for details

Warranty

Steel contruction - 15 years, electronics - 3 years, castors - 3 years.

Websites

• Jomor Healthcare - Rivoli Ultra Low Bed - http://www.jomor.healthcare/rivoli-bed/

Maintenance

Refer to the supplier and manufacturer manual for maintenance instructions and safety warnings.

Models / Specifications

Features

Contact listed suppliers to confirm features, options and models available.

Optional Accessories

• Bed accessories:
  • backlit handset
  • battery back-up
  • bed rail protectors
  • bed rails
  • IV pole
  • lock out handset
  • mattress retainer
  • self help pole
  • underbed lighting
  • urine bottle holder
  • wall bumpers
  • wireless handset

Motor

• Bed motor:
  • located centrally under the bed

Castors

• Castors:
  • dual castors
  • lockable (front castors)
  • lockable (rear castors)
  • semi-central locking castors
  • swivel type

Bed rails

• Bed rail options:
  • bed rail protectors
  • fold down
  • side safety rail
• Bed rails:
  • optional

Controls

• Bed control options:
  • backlit handset
  • handheld wireless control
  • Nurse lock-out (to prevent the user from operating the control panel)
• Bed controls:
  • handheld control on extendable cord
  • push button

Adjustment

• Bed adjustments:
  • electric back angle adjustment
  • electric knee bend
  • hi-lo height adjustment
  • reverse trendelenberg tilt
  • trendelenberg tilt

Footboard

• Bed footboard:
  • optional
  • removable
  • wood

Headboard

• Bed headboard:
  • optional
  • removable
  • wood

Frame

• Bed frame options:
  • bed extension
• Bed frame:
  • epoxy coated
  • four section
  • height adjustable
  • steel
• Bed mattress platform:
  • four section
  • ventilated flat sheet

Power Source

• Power source:
  • electric plug point into mains
